Rotel RA-1572 MKII Stereo Integrated Amplifier

The RA-1572MKII Integrated Amplifier is an essential component for music lovers leveraging the best of Rotel’s analog and digital technologies bringing music to life with exceptional fidelity. The role of an integrated amplifier continues to evolve with the RA-1572MKII optimized in every aspect including the power amplifier delivering 120 Watts of robust Class AB output into 8 ohms, audio circuit design innovations, premium audiophile Digital to Analog Converter and a full complement of source inputs.

FEATURES

• Certified Roon Tested
• Supports MQA and MQA Studio
• 2 x 200 Watts of robust Class AB power
• Moving magnet phono input for turntable
• Wireless aptX™ and AAC Bluetooth

TECHNICAL SPECS

• POWER REQUIREMENTS: 120V, 60Hz
• POWER CONSUMPTION: 400W
• STANDBY POWER CONSUMPTION: <0.5W
• DIMENSIONS (W × H × D): 431 × 144 × 358mm (17″ × 5.7″ × 14.1″)
• NET WEIGHT: 13.63kg (30.05lbs.)
• TOTAL HARMONIC DISTORTION(THD): <0.018%
• FREQUENCY RESPONSE
• Line Level Inputs:10Hz – 100kHz, ±0.5dB
• Digital Inputs:10Hz – 90kHz, ±2dB
• Phono Input:20Hz – 20kHz, ±0.5dB
• DAMPING FACTOR: 300
• INPUT SENSITIVITY
• Line Level Inputs (RCA): 270mV
• Line Level Inputs (XLR): 440mV
• Digital Inputs: 0 dBFs
• Phono Input (MM): 2.1mV
• INPUT IMPEDANCE
• Line Level Inputs (RCA): 100kΩ
• Line Level Inputs (XLR): 100kΩ
• Digital Inputs: 75Ω
• Phono Input (MM): 47kΩ
