Infinity Reference 6001 – Mono, 600w X 1 Amplifier With Remote Level Control

Infinity’s Reference 6001A mono subwoofer amplifier will add some bass muscle to your music without breaking a sweat, and it’ll look good doing it. This powerhouse delivers 600-Watts RMS to your subwoofer, and its Class D design ensures the amp’s high output will put minimal strain your vehicle’s electrical system. Speaker-level inputs allow this amplifier to work in almost any system, even if you’re hanging on to your factory radio. You can use the low-pass filter and variable bass boost to maximize the performance of your subwoofer and enclosure, while a phase switch ensures that the bass will blend well with your full-range speakers.

FEATURES

• Compact size
• High and low level input
• Variable crossover and bass boost
• Low noise and distortion
• Input Level Control
• Full on-board protection
• Phase Switch
• RBC wired remote
• Class D amp technology
• Turn-on mode

TECHNICAL SPECS

• Mono subwoofer car amplifier
• 350 watts RMS x 1 at 4 ohms (600 watts RMS x 1 at 2 ohms)
• Class D amp technology
• Variable low-pass filter (32–320Hz, 12dB/octave)
• Variable bass boost (0–12dB at 45Hz)
• Phase switch (0, 180 degrees)
• Preamp and speaker-level inputs
• Fuse rating: 30A x 2
• 8-gauge power and ground leads recommended — wiring and hardware not included with amplifier
• W x H x D = 220mm x 55.5mm x 180mm
• W x H x D = 8-11/16″ x 2-3/16″ x 7-1/8″

WHAT’S IN THE BOX

• One Reference 6001A mono subwoofer car amplifier
• Four 30A ATO fuses (2 installed, 2 spare)
• 2 Bare wire-to-RCA adapters
• Remote bass control module
• 16.5′ Remote control cable (RJ-25 plugs on both ends)
• 2 Self-tapping screws for remote (M3 x 15mm)
• 4 Mounting screws (M4 x 53mm)
• Owner’s Manual
• 2 Infinity decals
• 1 logo badage
