AVM – CS 5.3 Evolution – All-In-One Streaming CD Receiver

The new CS 5.3 all-in-one network streamer occupies the middle position between AVM’s entry level CS 2.3 and its flagship CS 8.3 all-in-one network streamers.

The CS 5.3 includes all the features and connectivity of AVM’s flagship CS 8.3 player, but also adds a high performance MM / MC phono stage with adjustable gain and loading.

The CS 5.3 also features AVM’s RC X APP which is a simple, easy to use app with a clear and intuitive user interface that makes managing large music collections child’s play.

AVM’s X-Stream Engine® can stream all high-resolution formats up to resolutions of 384/32, including DSD (256). This streaming engine was developed in-house by AVM and is completely software based so it can be updated online providing a future-proof platform. Supported formats include: Spotify, TIDAL Connect, QOBUZ, and Webradio and more to come in the future.

The digital section of the CS 5.3 was completely upgraded with the new ESS9028 PRO Double-Quad DAC. The new circuit uses four DACs per channel in parallel and offers a substantial improvement in sound quality. It reproduces all high-resolution formats as close to the original as possible.

One of the unique aspects of the CS 5.3 is its Tube Line Stage, which is located in the preamplifier section of the CS 5.3. Thanks to tubes specially made for AVM, and AVM’s proprietary circuit technology, the CS 5.3 delivers resolution and tonal charm rarely found in all-in-one components. With approximately 20,000 hours playing time, the tubes will last almost forever.

In terms of sound quality the CS 5.3 delivers a significant gain over the predecessor. The completely new amplifier stages now provide an impressive 180W of continuous power and can easily handle any loudspeaker.

“The EVOLUTION CS 5.3 is one of the most powerful all-in-ones we have ever tested. Likewise, it does not stray from subtle tones, thanks to its high-performance tube preamp. The RC X remote control app is comprehensive and well thought out. The feature set is immense, and the workmanship is on the highest level. The EVOLUTION CS 5.3 is a true Swiss Army Knife and a super sports car at the same time.”

Andreas Eichelsdörfer, Audio

In comparison to the entry-level CS 2.3, which is analogous to most other company’s flagship all-in-ones, the CS 5.3 features include: a more sophisticated design, higher quality components used in the analog circuit, analog inputs that are switched by higher quality relay, (instead of IC), a larger more robust aluminum chassis, two pair of speaker outputs, an upgraded headphone amplifier, an upgraded phono stage more analog inputs and outputs.

FEATURES:

All-in-One Streaming CD Receiver with 2 x 350 W
Speaker A & B
X-Stream Engine® for HiRes streaming incl. DSD, controllable over RC X APP
Prepared for Spotify, QOBUZ, TIDAL Connect, Webradio (upgradeable)
High performance phono input and switchable with complete adjustment possibilities MM & MC in the personal set-up menu (CS HMI or with the RC X APP)
HDMI (ARC) Input
2 digital inputs (SPDIF coax & opt.)
USB A for external hard drives (NTFS & FAT)
3 RCA + 1 XLR line inputs, switchable as signal sensitive inputs, switchable as Hometheatre Thruput
Bluetooth 4.2, Airplay 2/1, ROON ready
AVM multiroom function
2 Digital outputs (SPDIF, opt.), also switchable to variable volume
Headphone output 6,3mm on the front panel with dedicated headphone amp
Pure CD Drive with Slot-in (Red-Book)
Digital signal conversion with selected Double-Quad DAC for max. 384/32 PCM (ESS 9028PRO) and/or DSD 256
Tone control and parametric loudness with bypass function (also over RC X APP)
Dimmable white graphic display with touchpoint sensoric and proximity sensor
Numerous menu functions (adjustable input sensitivity, individual naming of inputs and many more)
Minimal standby power consumption (APD)
Compact size: 43mm x 12mm x 350mm (WHD)
Housing versions: Hand brushed aluminum silver or black or as CELLINI version with chrome front panel (additional charges apply)
Trigger in, ext. IR Sensor, 2 x Trigger out
